Strwythur sych a blocio dŵr
Gwrthiant tynnol a mathru rhagorol
Mae'r dyluniad fflutiog yn ei gwneud hi'n hawdd i stripio a splicing
Ceblau mewn dwythell
Ftth (ffibr i'r cartref)
Wedi'i derfynu ymlaen llaw yn y ffatri
|
Nifwynig |
Heitemau |
Materol |
|
1 |
Gwain fewnol |
Pvc 、 lszh |
|
2 |
Aelod Cryfder |
Gwifren Ddur, FRP, KFRP |
|
3 |
Ffibrau |
G.652D (B1.3), G.657A1 (B6A1), G.657A2 (B6A2)… |
|
4 |
Cefnogi Aelod Cryfder |
Gwifren ddur, frp |
|
5 |
Deunydd blocio dŵr |
Tâp blocio dŵr |
|
6 |
Gwain allanol |
Lszh 、 pe |
|
7 |
Lliwia ’ |
Duon |
|
Math o gebl |
Dimensiwn |
Cryfder tynnol |
Gwrthiant mathru |
Radiws plygu |
||||
|
Unedau |
Nghebl |
Hirdymor |
Nhymor |
Hirdymor |
Nhymor |
Statig |
Ddeinamig |
|
|
(mm) |
(N)) |
(N/100mm) |
— |
|||||
|
GJYXFH03 - 1/2/4 |
2.0 × 3.0 |
6.2 |
300 |
600 |
1000 |
2200 |
10 · D. |
20 · D. |
|
John03 - 1/2/4 |
2.0 × 3.0 |
6.2 |
300 |
600 |
1000 |
2200 |
10 · D. |
20 · D. |
Nodiadau: D = diamedr cebl.
|
Math o Ffibr |
Gwanhau |
Colled Macro Bend (Max) |
|||||
|
1310nm |
1550nm |
Φ30mm 10 Cylch (Troi) |
Φ20mm 1 cylch (troi) |
Φ15mm 1 cylch (troi) |
Φ32mm 1 cylch (troi) |
Φ60mm 100 cylch (troadau) |
|
|
(db/km) |
(db) |
||||||
|
G.652 D. |
0.40 |
0.30 |
Amherthnasol |
Amherthnasol |
Amherthnasol |
0.05 @1550nm |
0.05 @1625nm |
|
G.657 A1 |
0.40 |
0.30 |
0.25 @1550nm 1.00 @1625nm |
0.75 @1550nm 1.50 @1625nm |
Amherthnasol |
Amherthnasol |
Amherthnasol |
|
G.657 A2 |
0.40 |
0.30 |
0.03 @1550nm 0.10 @1625nm |
0.1 @1550nm 0.2 @1625nm |
0.5 @1550nm 1.0 @1625nm |
Amherthnasol |
Amherthnasol |
|
Cludiant a Storio |
Gosodiadau |
Gweithrediad |
Sylwadau |
|
-40 ℃ - +60 ℃ |
-30 ℃ - +50 ℃ |
-40 ℃ - +60 ℃ |
Rohs |
Gellir addasu'r holl werthoedd uchod.
